Description
24" IPS technology panel with USB-C dock and RJ45 (LAN)
Equipped with a USB-C dock connector, the XUB2492HSN allows you to simplify your workspace by using a single cable to both send signal from your notebook to your monitor and power and charge the notebook from the monitor. Additionally, if your monitor is connected to the Internet with a LAN cable, your notebook will automatically be connected to the network as well. Thanks to a DisplayPort output you can easily extend your desktop by creating a double-monitor set-up. Supplied with a 150mm height-adjustable stand featuring pivot and swivel functions, the XUB2492HSN allows you to easily adjust the screen position to your preferences.
USB-C DOCK
The dock allows you to connect your laptop with a single cable to the monitor to both make sure it is charged and connected to a wired network and signal from the laptop is sent to the monitor. A second monitor can be connected to the DisplayPort (MST) output to create a multi-monitor set-up. With additional USB-ports, your mouse, keyboard or webcam can also be connected to the monitor. All thanks to a single cable connecting your laptop* to the USB C dock in the monitor.
*Functions vary depending on your laptop USB-C support.
Equipped with a USB-C dock connector, the XUB2492HSN allows you to simplify your workspace by using a single cable to both send signal from your notebook to your monitor and power and charge the notebook from the monitor. Additionally, if your monitor is connected to the Internet with a LAN cable, your notebook will automatically be connected to the network as well. Thanks to a DisplayPort output you can easily extend your desktop by creating a double-monitor set-up. Supplied with a 150mm height-adjustable stand featuring pivot and swivel functions, the XUB2492HSN allows you to easily adjust the screen position to your preferences.
USB-C DOCK
The dock allows you to connect your laptop with a single cable to the monitor to both make sure it is charged and connected to a wired network and signal from the laptop is sent to the monitor. A second monitor can be connected to the DisplayPort (MST) output to create a multi-monitor set-up. With additional USB-ports, your mouse, keyboard or webcam can also be connected to the monitor. All thanks to a single cable connecting your laptop* to the USB C dock in the monitor.
*Functions vary depending on your laptop USB-C support.
Specification
Design | |
---|---|
Product colour | Black |
Frameless design | Yes |
Front bezel colour | Black |
Certification | TCO Certified, CE, TÜV-GS, EAC, VCCI-B, PSE, RoHS support, ErP, WEEE, REACH, UKCA |
Display | |
Display diagonal | 61 cm (24") |
Display resolution | 1920 x 1080 pixels |
HD type | Full HD |
Native aspect ratio | 16:9 |
Display technology | LED |
Panel type | IPS |
Backlight type | LED |
Touchscreen | No |
Display brightness (typical) | 250 cd/m² |
Response time | 4 ms |
Display surface | Matt |
Screen shape | Flat |
Aspect ratio | 16:9 |
Contrast ratio (typical) | 1000:1 |
Maximum refresh rate | 75 Hz |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Display number of colours | 16.7 million colours |
Digital horizontal frequency | 30 - 85 kHz |
RGB colour space | sRGB |
sRGB coverage (typical) | 99% |
Ergonomics | |
VESA mounting | Yes |
Panel mounting interface | 100 x 100 mm |
Cable management | Yes |
Height adjustment | Yes |
Height adjustment | 15 cm |
Pivot | Yes |
Pivot angle | 0 - 90° |
Swivelling | Yes |
Swivel angle range | 45 - 90° |
Tilt angle range | 5 - 23° |
On Screen Display (OSD) | Yes |
On Screen Display (OSD) languages | Czech, German, Dutch, English, Estonian, French, Italian, Japanese, Polish, Russian |
Number of OSD languages | 10 |
Multimedia | |
Built-in speaker(s) | Yes |
Built-in camera | No |
Number of speakers | 2 |
RMS rated power | 2 W |
Network | |
Ethernet LAN | Yes |
Packaging content | |
Stand included | Yes |
Cables included | AC, HDMI, USB Type-C |
Quick start guide | Yes |
Manual | Yes |
Packaging data | |
Package width | 608 mm |
Package height | 395 mm |
Package weight | 7 kg |
Package type | Box |
Package depth | 150 mm |
Performance | |
Flicker-free technology | Yes |
Low Blue Light technology | Yes |
Ports & interfaces | |
Built-in USB hub | Yes |
USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
USB upstream port type | USB Type-A |
Number of upstream ports | 2 |
Number of USB Type-C upstream ports quantity | 1 |
USB Power Delivery | Yes |
USB Power Delivery up to | 65 W |
HDMI | Yes |
HDMI ports quantity | 1 |
DisplayPorts quantity | 1 |
Headphone out | Yes |
Headphone outputs | 1 |
HDCP | Yes |
Power | |
Energy efficiency class (SDR) | E |
Energy consumption (SDR) per 1000 hours | 17 kWh |
Power consumption (typical) | 17 W |
Power consumption (standby) | 0.5 W |
Power consumption (off) | 0.3 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Energy efficiency scale | A to G |
Weight & dimensions | |
Width (with stand) | 539.5 mm |
Depth (with stand) | 209.5 mm |
Height (with stand) | 493 mm |
Weight (with stand) | 5.6 kg |
Features
61 cm (24") LED IPS |
Full HD 1920 x 1080 pixels 16:9 |
75 Hz 4 ms 250 cd/m² 1000:1 |
Flicker-free technology |
E 17 kWh 17 W |
